Cyberoam iView

Enterprises and MSSPs need a solution that gives them visibility into network activities and security posture from a single location. Cyberoam iView offers centralized logging and reporting of network and user activity over multiple devices across distributed locations for security events. It offers logs and reports of Cyberoam network security appliances, along with other UTMs and NGFW appliances, routers and switches.

iView is available in two types:

iView Hardware
iView Software

Facilities and Features

iView Features

Aggregated & Comprehensive Reporting
Security Management
Log Management
Identity-based Reporting
Compliance Management
Forensic Analysis
Compatibility with wide range of devices/solutions

iView Hardware and Software

iView Hardware

Next-Generation Reporting series of Cyberoam iView appliances (iView NR) are built using a powerful hardware for faster processing and more events per second; more effective storage capacity and per day storage limits; and a higher average retention duration. The new software architecture improves performance besides offering a smart UI.

CR-iVU200NR	CR-iVU100NR	CR-iVU25NR	Performance
1750	1250	500	Events per Second (EPS)
350	250	100	Devices Supported (Max)
60	43	17	GB/day of logs (Max)
7 years	5/3 years	6 month	Average retention at 4GB logs/day

iView Software
Cyberoam iView is available as an open source solution for the logging and reporting needs in organizational networks. As open source software, iView allows customization to meet specific requirements of networks.

Technical Specifications iview

Hardware Specifications	CR-iVU25NR	CR-iVU100NR	CR-iVU200NR
Interfaces
Ethernet Ports (GbE)	4	6	6
Console Ports (RJ45)	1	1	1
USB Ports	2	1	1
CF Card (GB)	4	4	4
Number of Hard Drives	1 (1TB)	4 (2TB each)	4 (4TB each)
Total Available Storage	1TB	8TB	16TB
RAID Storage Management	–	RAID 5	RAID 5
Performance
Events per Second (EPS)	500	1,250	1,750
Devices Supported (Max)	100	250	350
GB/day of logs (Max)	17	43	60
Average retention at 4GB logs/day	6 months	3.5 years	7 years
Dimensions	6 months	3.5 years	7 years
H x W x D (inches)	1.72 x 10.83 x 17.32	3.46 x 16.7 x 20.9	3.46 x 16.7 x 20.9
H x W x D (cms)	4.4 x 27.5 x 44	8.8 x 42.4 x 53.1	8.8 x 42.4 x 53.1
Weight	3.78kg, 8.35lbs	16 kg, 36lbs	16 kg, 36lbs
Power
Input Voltage	100-240 VAC	100-240 VAC	100-240 VAC
Consumption	65W	265W	265W
Total Heat Dissipation (BTU)	175	425	425
Environmental
Operating Temperature	5 to 40 °C	5 to 40 °C	5 to 40 °C
Storage Temperature	20 to 70 °C	20 to 70 °C	20 to 70 °C
Relative Humidity (Non condensing)	20 to 70%	20 to 70%	20 to 70%
